I. Equipment features

1. the device supports real-time monitoring of UVLED current, UVLED fault alarm function and energy-saving protection function.

2. the device provides continuous mode, back-end mode, regional mode optional; continuous mode: click the start button, UV curing machine conveyor belt and UVLED has been working, click the stop button UV machine stops working; back-end mode: click the start button, the UV machine conveyor belt and the UVLED began to work, when the back-end sensor sensor to sense the product, the conveyor belt and the UVLED stops working when the product is taken away to continue into the next cycle; regional mode: click the start button UV curing machine conveyor belt began to work, when the product After taking away the product, the conveyor belt and UVLED stop working, when the product continues to enter the next cycle; area mode: click the start button UV curing machine conveyor belt began to work, when the front end of the region to detect the product UVLED began to work, when the back end of the region to detect the product left, UVLED stop working, when the back end of the sensor sensor sensors, the conveyor belt stops working, when the product is taken away to continue to enter the next cycle.

3. UV curing machine equipment with digital dimming, delayed shutdown fan heat fan, history of irradiation time query and other functions.

Second, the light source characteristics

1. energy efficient

UVLED output band concentration, high photoelectric conversion rate, energy saving, fast curing speed, high productivity.

2、Wide range of application

UVLED is a cold light source, low infrared heat radiation, will not cause thermal stress and deformation, suitable for all kinds of heat-sensitive materials curing.

3、Long life

UVLED long life, reduce the investment cost of equipment. That is on and off, no need to warm up, the number of switches does not affect the service life.

4、Green

UV curing machine equipment light source in line with RoHS, does not contain mercury.
